SUNFIELD is your ideal online supplier of PTO shafts for your farm machinery
SUNFIELD is your online source for PTO shafts. You rely on your PTO shaft to get your crops done in time, so rely on SUNFIELD for your power take off needs. Order online and find the PTO shaft you need.
SUNFIELD makes it easy to find and order the PTO shaft that you need
At the highest quality and value, we will ensure you have the part you need to get your equipment back to work in no time. SUNFIELD will ship your PTO shaft to anywhere in the continental US, and we’ll do it fast. It’s important that your equipment doesn’t stay idle when you need to work, so we’ll be sure to expedite your delivery.
We’ll also give you a limited warranty on your PTO shaft
We take immense pride in our product, and we know how much you value quality. If you find your shaft is defective in the *first year of use, we’ll cover it. PTO shafts have a rough and tough life, ensuring you can get your work done, so we know you need an assurance of highly robust manufacture.
How to adjust a PTO driveline.
In the collapsed position the driveline should be approximately 2″ from bottoming out to prevent possible damage to the tractor or implement. When the PTO is in the maximum extended position, the ideal minimum overlap of the two halves should be approximately 6″ (see figure on right). If determined that the drive line is too long, follow these procedures to adjust the length: separate the two drive line halves. Connect one half to the tractor PTO and the other half to the implement. Raise and lower the machine with the 3 point hitch to find the position where the driveline is shortest. Hold the half shafts side by side and mark the desired length on the outer female guard tube leaving a 2″ gap between the end of the guard tube and bell guard. Cut off both guard tubes the same amount as marked in step 2. Shorten both drive tubes the same amount as guard tubes. De-burr and clean filings from drive tubes and apply grease to outside of inner telescoping tube. Reassemble the drive line halves and connect to tractor and implement. Raise and lower implement again to be sure drive line does not bottom out in shortest position and has a minimum overlap of 6″ in the longest position.
SUNFIELD GROUP CO., LTD.
IS SPECIALIST IN MAKING ALL KINDS OF MECHANICAL TRANSMISSION AND HYDRAULIC TRANSMISSION LIKE: PLANETARY GEARBOXES, WORM REDUCERS, IN-LINE HELICAL GEAR SPEED REDUCERS, PARALLEL SHAFT HELICAL GEAR REDUCERS, HELICAL BEVEL REDUCERS, HELICAL WORM GEAR REDUCERS, AGRICULTURAL GEARBOXES, TRACTOR GEARBOXES, AUTO GEARBOXES, PTO DRIVE SHAFTS, SPECIAL REDUCER & RELATED GEAR COMPONENTS AND OTHER RELATED PRODUCTS, SPROCKETS, HYDRAULIC SYSTEM, VACCUM PUMPS, FLUID COUPLING, GEAR RACKS, CHAINS, TIMING PULLEYS, UDL SPEED VARIATORS, V PULLEYS, HYDRAULIC CYLINDER, GEAR PUMPS, SCREW AIR COMPRESSORS, SHAFT COLLARS LOW BACKLASH WORM REDUCERS AND SO ON. FURTHERMORE, WE CAN PRODUCE CUSTOMIZED VARIATORS, GEARED MOTORS, ELECTRIC MOTORS AND OTHER HYDRAULIC PRODUCTS ACCORDING TO CUSTOMERS’ DRAWINGS
